Gateways for Hitachi air conditioners | Ventalen

Air-conditioning series	Model	Gateway	Documentation
Split systems
Series Shiratama	RAK-DJ18RHAE \| RAC-DJ18WHAE	HT-1-MB-B	Documentation
	RAK-DJ25RHAE \| RAC-DJ25WHAE
	RAK-DJ35RHAE \| RAC-DJ35WHAE
	RAK-DJ50RHAE \| RAC-DJ50WHAE
Series X-Comfort	RAK-18REF \| RAC-18WEF	HT-1-MB-B	Documentation
	RAK-25REF \| RAC-25WEF
	RAK-35REF \| RAC-35WEF
	RAK-50REF \| RAC-50WEF
High-capacity wall-mounted units	RAK-60RPE \| RAC-60NPE	HT-1-MB-B	Documentation
	RAK-70PPD \| RAC-70NPD
Ducted units	RAD-25RPE \| RAC-25NPE	HT-1-MB-B	Documentation
	RAD-35RPE \| RAC-35NPE
	RAD-50RPE \| RAC-50NPE
	RAD-60RPE \| RAC-60NPE
	RAD-70PPD \| RAC-70NPD
Multi-split systems
Wall-mounted units series Multizone Comfort	RAK-18REF	HT-1-MB-B	Documentation
	RAK-25REF
	RAK-35REF
	RAK-50REF
Wall-mounted units series Multizone Premium	RAK-15QPE	HT-1-MB-B	Documentation
	RAK-18RPE
	RAK-25RPE
	RAK-35RPE
	RAK-42RPE
	RAK-50RPE
Ducted units series Multizone Premium	RAD-18QPE	HT-1-MB-B	Documentation
	RAD-25RPE
	RAD-35RPE
	RAD-50RPE
	RAD-60RPE
Outdoor units
Outdoor units series Multizone Comfort	\| RAM-40NE2F	Not supported	Documentation
	\| RAM-53NE2F
	\| RAM-53NE3F
Outdoor units series Multizone Premium	\| RAM-33NP2E	Not supported	Documentation
	\| RAM-40NP2E
	\| RAM-53NP2E
	\| RAM-53NP3E
	\| RAM-68NP3E
	\| RAM-70NP4E
	\| RAM-90NP5E
	\| RAM-110NP5E

Air-conditioning series	Model	Gateway	Documentation
VRF systems
High-static ducted units	HIDH015B23S	Not supported	Documentation
	HIDH015B24S
	HIDH018B23S
	HIDH018B24S
	HIDH024B23S
	HIDH024B24S
	HIDH027B23S
	HIDH027B24S
	HIDH030B23S
	HIDH030B24S
	HIDH036B23S
	HIDH036B24S
	HIDH048B23S
	HIDH048B24S
	HIDH054B23S
	HIDH054B24S
	HIDH072B21S
	HIDH096B21S
Medium-static ducted units	HIDM006B23S	Not supported	Documentation
	HIDM006B24S
	HIDM008B23S
	HIDM008B24S
	HIDM012B23S
	HIDM012B24S
	HIDM015B23S
	HIDM015B24S
	HIDM018B23S
	HIDM018B24S
	HIDM024B23S
	HIDM024B24S
	HIDM027B23S
	HIDM027B24S
	HIDM030B23S
	HIDM030B24S
	HIDM036B23S
	HIDM036B24S
	HIDM048B23S
	HIDM048B24S
	HIDM054B23S
	HIDM054B24S
Slim ducted units	HIDS006B21S	Not supported	Documentation
	HIDS008B21S
	HIDS012B21S
	HIDS015B21S
	HIDS018B21S
Ducted units with fresh-air intake	HDOA096B21S	Not supported	Documentation
Ducted units EconoFresh	HIDM030B21E	Not supported	Documentation
	HIDM036B21E
	HIDM048B21E
One-way cassette units	HIC1006B2B2S	Not supported	Documentation
	HIC1006B2B3S
	HIC1008B2B2S
	HIC1008B2B3S
	HIC1012B2B2S
	HIC1012B2B3S
	HIC1015B2B2S
	HIC1015B2B3S
Two-way cassette units	HIC2018B21S	Not supported	Documentation
	HIC2018B22S
	HIC2024B21S
	HIC2024B22S
Compact four-way cassette units	HICM008B21S	Not supported	Documentation
	HICM012B21S
	HICM015B21S
	HICM018B21S
Four-way cassette units	HIC4008B21S	Not supported	Documentation
	HIC4008B22S
	HIC4012B21S
	HIC4012B22S
	HIC4015B22S
	HIC4015B22S
	HIC4018B21S
	HIC4018B22S
	HIC4024B21S
	HIC4024B22S
	HIC4030B21S
	HIC4030B22S
	HIC4036B21S
	HIC4036B22S
	HIC4048B21S
	HIC4048B22S
Ceiling-mounted units	HICS015B22S	Not supported	Documentation
	HICS015B23S
	HICS024B22S
	HICS024B23S
	HICS030B22S
	HICS030B23S
	HICS036B22S
	HICS036B23S
Wall-mounted units	TIWM006B22S	Not supported	Documentation
	TIWM006B23S
	TIWM008B22S
	TIWM008B23S
	TIWM012B22S
	TIWM012B23S
	TIWM015B22S
	TIWM015B23S
	TIWM018B22S
	TIWM018B23S
	TIWM024B22S
	TIWM024B23S
	TIWM030B22S
	TIWM030B23S
Floor-standing units	HIFE006B21S	Not supported	Documentation
	HIFE008B21S
	HIFE012B21S
	HIFE015B21S
VRF outdoor units
Outdoor units	\| HVAHR072B32S	Not supported	Documentation
	\| HVAHR072B42S
	\| HVAHR072B52S
	\| HVAHR096B32S
	\| HVAHR096B42S
	\| HVAHR096B52S
	\| HVAHR120B32S
	\| HVAHR120B42S
	\| HVAHR120B52S
	\| HVAHR144B32S
	\| HVAHR144B42S
	\| HVAHR144B52S
	\| HVAHR168B32S
	\| HVAHR168B42S
	\| HVAHR168B52S
	\| HVAHR192B32S
	\| HVAHR192B42S
	\| HVAHR192B52S
	\| HVAHR216B32S
	\| HVAHR216B42S
	\| HVAHR216B52S
	\| HVAHR240B32S
	\| HVAHR240B42S
	\| HVAHR240B52S
	\| HVAHR264B32S
	\| HVAHR264B42S
	\| HVAHR264B52S
	\| HVAHR288B32S
	\| HVAHR288B42S
	\| HVAHR288B52S
	\| HVAHR312B32S
	\| HVAHR312B42S
	\| HVAHR312B52S
	\| HVAHR336B32S
	\| HVAHR336B42S
	\| HVAHR336B52S
	\| HVAHR360B32S
	\| HVAHR360B42S
	\| HVAHR360B52S
	\| HVAHR384B32S
	\| HVAHR384B42S
	\| HVAHR384B52S
	\| HVAHR408B32S
	\| HVAHR408B42S
	\| HVAHR408B52S
	\| HVAHR432B32S
	\| HVAHR432B42S
	\| HVAHR432B52S
	\| HVAHR072B33CW
	\| HVAHR072B43CW
	\| HVAHR072B53CW
	\| HVAHR096B33CW
	\| HVAHR096B43CW
	\| HVAHR096B53CW
	\| HVAHR120B33CW
	\| HVAHR120B43CW
	\| HVAHR120B53CW
	\| HVAHR144B33CW
	\| HVAHR144B43CW
	\| HVAHR144B53CW
	\| HVAHR168B33CW
	\| HVAHR168B43CW
	\| HVAHR168B53CW
	\| HVAHR192B33CW
\| HVAHR192B43CW
\| HVAHR192B53CW
\| HVAHR216B33CW
\| HVAHR216B43CW
\| HVAHR216B53CW
\| HVAHR240B33CW
\| HVAHR240B43CW
\| HVAHR240B53CW
\| HVAHR264B33CW
\| HVAHR264B43CW
\| HVAHR264B53CW
\| HVAHR288B33CW
\| HVAHR288B43CW
\| HVAHR288B53CW
\| HVAHP072B32S
\| HVAHP072B42S
\| HVAHP072B52S
\| HVAHP096B32S
\| HVAHP096B42S
\| HVAHP096B52S
\| HVAHP120B32S
\| HVAHP120B42S
\| HVAHP120B52S
\| HVAHP144B32S
\| HVAHP144B42S
\| HVAHP144B52S
\| HVAHP168B32S
\| HVAHP168B42S
\| HVAHP168B52S
\| HVAHP192B32S
\| HVAHP192B42S
\| HVAHP192B52S
\| HVAHP216B32S
\| HVAHP216B42S
\| HVAHP216B52S
\| HVAHP240B32S
\| HVAHP240B42S
\| HVAHP240B52S
\| HVAHP264B32S
\| HVAHP264B42S
\| HVAHP264B52S
\| HVAHP288B32S
\| HVAHP288B42S
\| HVAHP288B52S
\| HVAHP312B32S
\| HVAHP312B42S
\| HVAHP312B52S
\| HVAHP336B32S
\| HVAHP336B42S
\| HVAHP336B52S
\| HVAHP360B32S
\| HVAHP360B42S
\| HVAHP360B52S
\| HVAHP384B32S
\| HVAHP384B42S
\| HVAHP384B52S
\| HVAHP408B32S
\| HVAHP408B42S
\| HVAHP408B52S
\| HVAHP432B32S
\| HVAHP432B42S
\| HVAHP432B52S
\| HVAHP036B21S
\| HVAHP048B21S
\| HVAHP060B21S

Air-conditioning series	Model	Gateway	Documentation
Split systems
Series Shiratama	RAK-DJ18PHAE \| RAC-DJ18PHAE	HT-1-MB-B	Documentation
	RAK-DJ25PHAE \| RAC-DJ25PHAE
	RAK-DJ35PHAE \| RAC-DJ35PHAE
	RAK-DJ50PHAE \| RAC-DJ50PHAE
	RAK-DJ60PHAE \| RAC-DJ60PHAE
	RAK-DJ70PHAE \| RAC-DJ70PHAE
Series X-Comfort	RAK-18REF \| RAC-18WEF	HT-1-MB-B	Documentation
	RAK-25REF \| RAC-25WEF
	RAK-35REF \| RAC-35WEF
	RAK-50REF \| RAC-50WEF
Series Sendo	RAK-18RPE \| RAC-18WPE	HT-1-MB-B	Documentation
	RAK-25RPE \| RAC-25WPE
	RAK-35RPE \| RAC-35WPE
	RAK-42RPE \| RAC-42WPE
	RAK-50RPE \| RAC-50WPE
High-capacity wall-mounted units	RAK-60RPE \| RAC-60NPE	HT-1-MB-B	Documentation
	RAK-70PPD \| RAC-70NPD
Heat pumps series Akebono Nordic	RAK-25RXE \| RAC-25WXEN	HT-1-MB-B	Documentation
	RAK-35RXE \| RAC-35WXEN
	RAK-50RXE \| RAC-50WXEN
Series S-Premium	RAK-25PSES \| RAC-25WSE	HT-1-MB-B	Documentation
	RAK-35PSES \| RAC-35WSE
	RAK-50PSES \| RAC-50WSE
Ducted units	RAD-25RPE \| RAC-25NPE	HT-1-MB-B	Documentation
	RAD-35RPE \| RAC-35NPE
	RAD-50RPE \| RAC-50NPE
	RAD-60RPE \| RAC-60NPE
	RAD-70PPD \| RAC-70NPD
Cassette units	RAI-25RPE \| RAC-25NPE	HT-1-MB-B	Documentation
	RAI-35RPE \| RAC-35NPE
	RAI-50RPE \| RAC-50NPE
	RAI-60RPE \| RAC-60NPE
Floor-standing units	RAF-25RXE \| RAC-25FXE	HT-1-MB-B	Documentation
	RAF-35RXE \| RAC-35FXE
	RAF-50RXE \| RAC-50FXE
Multi-split systems
Wall-mounted units series Multizone Comfort	RAK-18REF	HT-1-MB-B	Documentation
	RAK-25REF
	RAK-35REF
	RAK-50REF
Wall-mounted units series Multizone Premium	RAK-15QPE	HT-1-MB-B	Documentation
	RAK-18RPE
	RAK-25RPE
	RAK-35RPE
	RAK-42RPE
	RAK-50RPE
	RAK-18QXE
	RAK-25RXE
	RAK-35RXE
	RAK-50RXE
Ducted units series Multizone Premium	RAD-18QPE	HT-1-MB-B	Documentation
	RAD-25RPE
	RAD-35RPE
	RAD-50RPE
	RAD-60RPE
Cassette units series Multizone Premium	RAI-25RPE	HT-1-MB-B	Documentation
	RAI-35RPE
	RAI-50RPE
	RAI-60RPE
Floor-standing units series Multizone Premium	RAF-25RXE	HT-1-MB-B	Documentation
	RAF-35RXE
	RAF-50RXE
Outdoor units
Outdoor units series Multizone Comfort	\| RAM-40NE2F	Not supported	Documentation
	\| RAM-53NE2F
	\| RAM-53NE3F
Outdoor units series Multizone Premium	\| RAM-33NP2E	Not supported	Documentation
	\| RAM-40NP2E
	\| RAM-53NP2E
	\| RAM-53NP3E
	\| RAM-68NP3E
	\| RAM-70NP4E
	\| RAM-90NP5E
	\| RAM-110NP5E

Air-conditioning series	Model	Gateway	Documentation
Split systems
Series X-Comfort	RAK-18REF \| RAC-18WEF	HT-1-MB-B	Documentation
	RAK-25REF \| RAC-25WEF
	RAK-35REF \| RAC-35WEF
	RAK-50REF \| RAC-50WEF
Series Sendo	RAK-18RPE \| RAC-18WPE	HT-1-MB-B	Documentation
	RAK-25RPE \| RAC-25WPE
	RAK-35RPE \| RAC-35WPE
	RAK-42RPE \| RAC-42WPE
	RAK-50RPE \| RAC-50WPE
High-capacity wall-mounted units	RAK-60RPE \| RAC-60NPE	HT-1-MB-B	Documentation
	RAK-70PPD \| RAC-70NPD
Heat pumps series Akebono Nordic	RAK-25RXE \| RAC-25WXEN	HT-1-MB-B	Documentation
	RAK-35RXE \| RAC-35WXEN
	RAK-50RXE \| RAC-50WXEN
Series S-Premium	RAK-25PSES \| RAC-25WSE	HT-1-MB-B	Documentation
	RAK-35PSES \| RAC-35WSE
	RAK-50PSES \| RAC-50WSE
Ducted units	RAD-25RPE \| RAC-25NPE	HT-1-MB-B	Documentation
	RAD-35RPE \| RAC-35NPE
	RAD-50RPE \| RAC-50NPE
	RAD-60RPE \| RAC-60NPE
	RAD-70PPD \| RAC-70NPD
Cassette units	RAI-25RPE \| RAC-25NPE	HT-1-MB-B	Documentation
	RAI-35RPE \| RAC-35NPE
	RAI-50RPE \| RAC-50NPE
	RAI-60RPE \| RAC-60NPE
Floor-standing units	RAF-25RXE \| RAC-25FXE	HT-1-MB-B	Documentation
	RAF-35RXE \| RAC-35FXE
	RAF-50RXE \| RAC-50FXE
Multi-split systems
Wall-mounted units series Multizone Comfort	RAK-18REF	HT-1-MB-B	Documentation
	RAK-25REF
	RAK-35REF
	RAK-50REF
Wall-mounted units series Multizone Premium	RAK-15QPE	HT-1-MB-B	Documentation
	RAK-18RPE
	RAK-25RPE
	RAK-35RPE
	RAK-42RPE
	RAK-50RPE
	RAK-18QXE		Documentation
	RAK-25RXE
	RAK-35RXE
	RAK-50RXE
Ducted units series Multizone Premium	RAD-18QPE	HT-1-MB-B	Documentation
	RAD-25RPE
	RAD-35RPE
	RAD-50RPE
	RAD-60RPE
Cassette units series Multizone Premium	RAI-25RPE	HT-1-MB-B	Documentation
	RAI-35RPE
	RAI-50RPE
	RAI-60RPE
Floor-standing units series Multizone Premium	RAF-25RXE	HT-1-MB-B	Documentation
	RAF-35RXE
	RAF-50RXE
Outdoor units
Outdoor units series Multizone Comfort	\| RAM-40NE2F	Not supported	Documentation
	\| RAM-53NE2F
	\| RAM-53NE3F
Outdoor units series Multizone Premium	\| RAM-33NP2E	Not supported	Documentation
	\| RAM-40NP2E
	\| RAM-53NP2E
	\| RAM-53NP3E
	\| RAM-68NP3E
	\| RAM-70NP4E
	\| RAM-90NP5E
	\| RAM-110NP5E

Air-conditioning series	Model	Gateway	Documentation
Split systems
Series S-Premium	RAK-25PSEW \| RAC-25WSE	HT-1-MB-B	Documentation
	RAK-25PSES \| RAC-25WSE
	RAK-35PSEW \| RAC-35WSE
	RAK-35PSES \| RAC-35WSE
	RAK-50PSEW \| RAC-50WSE
	RAK-50PSES \| RAC-50WSE
Series Premium	RAK-18PSC \| RAC-18WSC	HT-1-MB-B	Documentation
	RAK-25PSC \| RAC-25WSC
	RAK-35PSC \| RAC-35WSC
Series Akebono R32	RAK-25RXE \| RAC-25WXE	HT-1-MB-B	Documentation
	RAK-35RXE \| RAC-35WXE
	RAK-50RXE \| RAC-50WXE
Series Akebono R410A	RAK-35RXB \| RAC-35WXB	HT-1-MB-B	Documentation
	RAK-35RXB \| RAC-35WXB
	RAK-50RXB \| RAC-50WXB
Series Performance R32	RAK-18RPE \| RAC-18WPE	HT-1-MB-B	Documentation
	RAK-25RPE \| RAC-25WPE
	RAK-35RPE \| RAC-35WPE
	RAK-42RPE \| RAC-42WPE
	RAK-50RPE \| RAC-50WPE
Series Performance R410A	RAK-18RPB \| RAK-18WED	HT-1-MB-B	Documentation
	RAK-25RPB \| RAK-25WED
	RAK-18RPC \| RAK-18WED
	RAK-25RPC \| RAK-25WED
	RAK-35RPC \| RAK-35WED
	RAK-50RPC \| RAK-50WED
Series Eco comfort R32	RAK-18PED \| RAK-18WED	HT-1-MB-B	Documentation
	RAK-25PED \| RAK-25WED
	RAK-35PED \| RAK-35WED
	RAK-50PED \| RAK-50WED
Series Eco comfort R410A	RAK-18PEC \| RAC-18WEC	HT-1-MB-B	Documentation
	RAK-25PEC \| RAC-25WEC
	RAK-35PEC \| RAC-35WEC
	RAK-50PEC \| RAC-50WEC
Floor-standing units series Akebono	RAF-25RXE \| RAC-25FXE	HT-1-MB-B	Documentation
	RAF-35RXE \| RAC-35FXE
	RAF-50RXE \| RAC-50FXE
Low-static ducted units	RAD-25RPE \| RAC-25NPE	HT-1-MB-B	Documentation
	RAD-35RPE \| RAC-35NPE
	RAD-50RPE \| RAC-50NPE
	RAD-60RPE \| RAC-60NPE
Four-way cassette units	RAI-25RPE \| RAC-25NPE	HT-1-MB-B	Documentation
	RAI-35RPE \| RAC-35NPE
	RAI-50RPE \| RAC-50NPE
	RAI-60RPE \| RAC-60NPE
Wall-mounted units series Light commertial	RAK-50PPD \| RAC-50NPD	HT-1-MB-B	Documentation
	RAK-60PPD \| RAC-60NPD
	RAK-70PPD \| RAC-70NPD
Ducted units series Light commercial	RAD-50PPD \| RAC-50NPD	HT-1-MB-B	Documentation
	RAD-60PPD \| RAC-60NPD
	RAD-70PPD \| RAC-70NPD
Cassette units series Light commertial	RAI-50PPD \| RAC-50NPD	HT-1-MB-B	Documentation
	RAI-60PPD \| RAC-60NPD
Multi-split systems series Multizone Premium
Wall-mounted units series Akebono	RAK-18QXB	HT-1-MB-B	Documentation
	RAK-25RXB
	RAK-35RXB
	RAK-50RXB
Wall-mounted units series Performance	RAK-15QPB	HT-1-MB-B	Documentation
	RAK-18RPB
	RAK-25RPB
	RAK-35RPC
	RAK-50RPC
Floor-standing units series Akebono	RAF-25RXB	HT-1-MB-B	Documentation
	RAF-35RXB
	RAF-50RXB
Medium-static ducted units	RAD-18QPB	HT-1-MB-B	Documentation
	RAD-25QPB
	RAD-35QPB
	RAD-50QPB
Four-way cassette units	RAI-25QPB	HT-1-MB-B	Documentation
	RAI-35QPB
	RAI-50QPB
Wall-mounted units series Akebono R32	RAK-18QXE	HT-1-MB-B	Documentation
	RAK-25RXE
	RAK-35RXE
	RAK-50RXE
Wall-mounted units series Performance R32	RAK-15QPE	HT-1-MB-B	Documentation
	RAK-18RPE
	RAK-25RPE
	RAK-35RPE
	RAK-50RPE
Floor-standing units series Akebono R32	RAF-25RXE	HT-1-MB-B	Documentation
	RAF-35RXE
	RAF-50RXE
Medium-static ducted units R32	RAD-18QPE	HT-1-MB-B	Documentation
	RAD-25RPE
	RAD-35RPE
	RAD-50RPE
	RAD-60RPE
Four-way cassette units R32	RAI-25RPE	HT-1-MB-B	Documentation
	RAI-35RPE
	RAI-50RPE
	RAI-60RPE
Outdoor units
Outdoor units series Multizone Premium	\| RAM-33NP2B	Not supported	Documentation
	\| RAM-40NP2B
	\| RAM-53NP2B
	\| RAM-53NP3B
	\| RAM-68NP3B
	\| RAM-70NP4B
	\| RAM-90NP5B
	\| RAM-110NP6B
	\| RAM-33NP2E
	\| RAM-40NP2E
	\| RAM-53NP2E
	\| RAM-53NP3E
	\| RAM-68NP3E
	\| RAM-70NP4E
	\| RAM-90NP5E
	\| RAM-110NP5E

Air-conditioning series	Model	Gateway	Documentation
Split systems
Series Premium	RAK-18PSC \| RAC-18WSB(C)	HT-1-MB-B	Documentation
	RAK-25PSC \| RAC-25WSB(C)
	RAK-35PSC \| RAC-35WSB(C
Series Akebono	RAK-25RXB \| RAC-25WXB	HT-1-MB-B	Documentation
	RAK-35RXB \| RAC-35WXB
	RAK-50RXB \| RAC-50WXB
Series Akebono R32	RAK-25RXD \| RAC-25WXB	HT-1-MB-B	Documentation
	RAK-35RXD \| RAC-35WXB
	RAK-50RXD \| RAC-50WXB
Series Performance	RAK-18RPB(C) \| RAC-18WPB(C)	HT-1-MB-B	Documentation
	RAK-25RPB(C) \| RAC-25WPB(C)
	RAK-35RPC \| RAC-35WPC
	RAK-50RPC \| RAC-50WPC
Series Performance R32	RAK-18RPD \| RAC-18WPD	HT-1-MB-B	Documentation
	RAK-25RPD \| RAC-25WPD
	RAK-35RPD \| RAC-35WPD
	RAK-42RPD \| RAC-42WPD
	RAK-50RPD \| RAC-50WPD
Series Eco Comfort	RAK-18PEC \| RAC-18WEC	HT-1-MB-B	Documentation
	RAK-25PEC \| RAC-25WEC
	RAK-35PEC \| RAC-35WEC
	RAK-50PEC \| RAC-50WEC
Series Eco Comfort R32	RAK-18PED \| RAK-18WED	HT-1-MB-B	Documentation
	RAK-25PED \| RAK-25WED
	RAK-35PED \| RAK-35WED
	RAK-50PED \| RAK-50WED
Floor-standing units series Akebono	RAF-25RXB \| RAC-25FXB	HT-1-MB-B	Documentation
	RAF-35RXB \| RAC-35FXB
	RAF-50RXB \| RAC-50FXB
Low-static ducted units	RAD-25RPA \| RAC-25NPA	HT-1-MB-B	Documentation
	RAD-35RPA \| RAC-35NPA
	RAD-50RPA \| RAC-50NPA
Low-static ducted units R32	RAD-25RPE \| RAC-25NPE	HT-1-MB-B	Documentation
	RAD-35RPE \| RAC-35NPE
	RAD-50RPE \| RAC-50NPE
	RAD-60RPE \| RAC-60NPE
Medium-static ducted units	RAD-50PPA \| RAC-50DPA	HT-1-MB-B	Documentation
	RAD-60PPA \| RAC-60DPA
	RAD-70PPA \| RAC-70DPA
Four-way cassette units	RAI-25RPA \| RAC-25NPA	HT-1-MB-B	Documentation
	RAI-35RPA \| RAC-35NPA
	RAI-50RPA \| RAC-50NPA
Four-way cassette units R32	RAI-25RPA \| RAC-25NPA	HT-1-MB-B	Documentation
	RAI-35RPA \| RAC-35NPA
	RAI-50RPA \| RAC-50NPA
	RAI-60RPE \| RAC-60NPE
Wall-mounted units series Light commertial	RAK-50PPD \| RAC-50NPD	HT-1-MB-B	Documentation
	RAK-60PPD \| RAC-60NPD
	RAK-70PPD \| RAC-70NPD
Ducted units series Light commertial	RAD-50PPD \| RAC-50NPD	HT-1-MB-B	Documentation
	RAD-60PPD \| RAC-60NPD
	RAD-70PPD \| RAC-70NPD
Cassette units series Light commertial	RAI-50PPD \| RAC-50NPD	HT-1-MB-B	Documentation
	RAI-60PPD \| RAC-60NPD
Multi-split systems
Wall-mounted units series Akebono	RAK-18QXB	HT-1-MB-B	Documentation
	RAK-25RXB
	RAK-35RXB
	RAK-50RXB
Wall-mounted units series Performance	RAK-15QPB	HT-1-MB-B	Documentation
	RAK-18RPB
	RAK-25RPB
	RAK-35RPC
	RAK-50RPC
Floor-standing units series Akebono	RAF-25RXB	HT-1-MB-B	Documentation
	RAF-35RXB
	RAF-50RXB
Medium-static ducted units	RAD-18QPB	HT-1-MB-B	Documentation
	RAD-25QPB
	RAD-35QPB
	RAD-50QPB
Four-way cassette units	RAI-25QPB	HT-1-MB-B	Documentation
	RAI-35QPB
	RAI-50QPB
Outdoor units
Outdoor units series Multizone Premium	\| RAM-33NP2B	Not supported	Documentation
	\| RAM-40NP2B
	\| RAM-53NP2B
	\| RAM-53NP3B
	\| RAM-68NP3B
	\| RAM-70NP4B
	\| RAM-90NP5B
	\| RAM-110NP6B

Air-conditioning series	Model	Gateway	Documentation
Split systems
Series Premium	RAK-18PSB(C) \| RAC-18WSB(C)	HT-1-MB-B	Documentation
	RAK-25PSB(C) \| RAC-25WSB(C)
	RAK-35PSB(C) \| RAC-35WSB(C)
Series Akebono	RAK-25RXB \| RAC-25WXB	HT-1-MB-B	Documentation
	RAK-35RXB \| RAC-35WXB
	RAK-50RXB \| RAC-50WXB
Series Performance	RAK-18RPB(C) \| RAC-18WPB(C)	HT-1-MB-B	Documentation
	RAK-25RPB(C) \| RAC-25WPB(C)
	RAK-35RPC \| RAC-35WPC
	RAK-50RPC \| RAC-50WPC
	RAK-60PPA \| RAC-60WPA
	RAK-70PPA \| RAC-70WPA
Series Eco Comfort	RAK-18PEC \| RAC-18WEC	HT-1-MB-B	Documentation
	RAK-25PEC \| RAC-25WEC
	RAK-35PEC \| RAC-35WEC
	RAK-50PEC \| RAC-50WEC
Series Eco Comfort R32	RAK-18PED \| RAK-18WED	HT-1-MB-B	Documentation
	RAK-25PED \| RAK-25WED
	RAK-35PED \| RAK-35WED
	RAK-50PED \| RAK-50WED
Low-static ducted units	RAD-25RPA \| RAC-25NPA	HT-1-MB-B	Documentation
	RAD-35RPA \| RAC-35NPA
	RAD-50RPA \| RAC-50NPA
Medium-static ducted units	RAD-50PPA \| RAC-50DPA	HT-1-MB-B	Documentation
	RAD-60PPA \| RAC-60DPA
	RAD-70PPA \| RAC-70DPA
Four-way cassette units	RAI-25RPA \| RAC-25NPA	HT-1-MB-B	Documentation
	RAI-35RPA \| RAC-35NPA
	RAI-50RPA \| RAC-50NPA
Wall-mounted units series Light commercial	RAK-50PPD	HT-1-MB-B	Documentation
	RAK-60PPD
	RAK-70PPD
Ducted units series Light commertial	RAD-50PPD	HT-1-MB-B	Documentation
	RAD-60PPD
	RAD-70PPD
Cassette units series Light commertial	RAI-50PPD	HT-1-MB-B	Documentation
	RAI-60PPD
Multi-split systems
Wall-mounted units series Akebono	RAK-18QXB	HT-1-MB-B	Documentation
	RAK-25RXB
	RAK-35RXB
	RAK-50RXB
Wall-mounted units series Performance	RAK-15QPB	HT-1-MB-B	Documentation
	RAK-18RPB
	RAK-25RPB
	RAK-35RPC
	RAK-50RPC
Floor-standing units series Akebono	RAF-25RXB	HT-1-MB-B	Documentation
	RAF-35RXB
	RAF-50RXB
Medium-static ducted units	RAD-18QPB	HT-1-MB-B	Documentation
	RAD-25QPB
	RAD-35QPB
	RAD-50QPB
Four-way cassette units	RAI-25QPB	HT-1-MB-B	Documentation
	RAI-35QPB
	RAI-50QPB
Outdoor units
Outdoor units series Light commertial	\| RAC-50NPD	Not supported	Documentation
	\| RAC-60NPD
	\| RAC-70NPD
Outdoor units series Multizone Premium	\| RAM-33NP2B	Not supported	Documentation
	\| RAM-40NP2B
	\| RAM-53NP2B
	\| RAM-53NP3B
	\| RAM-68NP3B
	\| RAM-70NP4B
	\| RAM-90NP5B
	\| RAM-110NP6B

Air-conditioning series	Model	Gateway	Documentation
Split systems
Series Premium	RAS-10XH1 \| RAC-10XH1	HT-1-MB-B	Documentation
	RAS-14XH1 \| RAC-14XH1
Series Eco Sensor	RAS-10SH3 \| RAC-10SH3	HT-1-MB-B	Documentation
	RAS-14SH3 \| RAC-14SH3
	RAS-18SH3 \| RAC-18SH3
Series Air Exchanger	RAS-10JH5 \| RAC-10JH5	Not supported	Documentation
	RAS-14JH5 \| RAC-14JH5
Series Premium Inverter	RAS-10MH1 \| RAC-10MH1	HT-1-MB-B	Documentation
	RAS-14MH1 \| RAC-14MH1
	RAS-18MH1 \| RAC-18MH1
	RAS-24MH1 \| RAC-24MH1
	RAS-30MH1 \| RAC-30MH1
Series Inverter	RAS-08PH1 \| RAC-08PH1	HT-1-MB-B	Documentation
	RAS-10PH1 \| RAC-10PH1
	RAS-14PH1 \| RAC-14PH1
	RAS-18PH1 \| RAC-18PH1
Series Luxury	RAS-08LH2 \| RAC-08LH1	Not supported	Documentation
	RAS-10LH2 \| RAC-10LH1
	RAS-14LH2 \| RAC-14LH1
	RAS-08LH2B \| RAC-08LH1
	RAS-10LH2B \| RAC-10LH1
	RAS-14LH2B \| RAC-14LH1
	RAS-18LH2 \| RAC-18LH1
	RAS-24LH2 \| RAC-24LH1
Series Business	RAS-08AH1 \| RAC-08AH1	Not supported	Documentation
	RAS-10AH1 \| RAC-10AH1
	RAS-14AH1 \| RAC-14AH1
Series Dualzone	RAS-08QH5E \| RAM-18QH5E	Not supported	Documentation
	RAS-10QH5E \| RAM-18QH5E
	RAS-14QH5E \| RAM-18QH5E
Multi-split systems
Wall-mounted units	RAK-18NH6AS	HT-1-MB-B	Documentation
	RAK-25NH6A
	RAK-35NH6A
	RAK-50NH6A
	RAK-65NH6A
Floor-standing units	RAF-25NX2	HT-1-MB-B	Documentation
	RAF-35NX2
	RAF-50NX2
Cassette units	RAI-25NH5A	HT-1-MB-B	Documentation
	RAI-35NH5A
	RAI-50NH5A
Ducted units	RAD-18NH7A	HT-1-MB-B	Documentation
	RAD-25NH7A
	RAD-35NH7A
	RAD-50NH7A
Multi-split outdoor units
Outdoor units series MULTIZONE	\| RAM-35QH5	Not supported	Documentation
	\| RAM-52QH5
	\| RAM-53QH5
	\| RAM-71QH5
	\| RAM-90QH5
	\| RAM-130QH5
VRF outdoor units
Series ES	\| RAS-3HVRNS3	Not supported	Documentation
	\| RAS-4HVRNS3E
	\| RAS-5HVRNS2E
	\| RAS-6HVRNS2E
	\| RAS-4HRNS3E
	\| RAS-5HRNS2E
	\| RAS-6HRNS2E
	\| RAS-8HRNSE
	\| RAS-10HRNSE
Series IVX Standart	\| RAS-3HVNC1	Not supported	Documentation
	\| RAS-4HVNC1E
	\| RAS-4HNC1E
	\| RAS-5HVNC1E
	\| RAS-5HNC1E
	\| RAS-6HVNC1E
	\| RAS-6HNC1E
	\| RAS-8HNCE
	\| RAS-10HNCE
	\| RAS-12HNC
Series IVX Premium	\| RAS-2HVNP1	Not supported	Documentation
	\| RAS-2.5HVNP1
	\| RAS-3HVNP1E
	\| RAS-4HVNP1E
	\| RAS-4HNP1E
	\| RAS-5HVNP1E
	\| RAS-5HNP1E
	\| RAS-6HVNP1E
	\| RAS-6HNP1E
	\| RAS-8HNPE
	\| RAS-10HNPE
	\| RAS-12HNP
Series IVX Centrifugal with centrifugal fans	\| RASC-4HNPE	Not supported	Documentation
	\| RASC-5HNPE
	\| RASC-6HNPE
	\| RASC-8HNPE
	\| RASC-10HNPE
Series Set Free Mini	\| RAS-4FSVN3E	Not supported	Documentation
	\| RAS-5FSVN3E
	\| RAS-6FSVN3E
	\| RAS-4FSNY3E
	\| RAS-5FSNY3E
	\| RAS-6FSNY3E
Series Set Free Side Flow	\| RAS-8FSNM	Not supported	Documentation
	\| RAS-10FSNM
	\| RAS-12FSNM
Modular series FSXN	\| RAS-8FSXN	Not supported	Documentation
	\| RAS-10FSXN
	\| RAS-12FSXN
	\| RAS-14FSXN
	\| RAS-16FSXN
	\| RAS-18FSXN
	\| RAS-20FSXN
	\| RAS-22FSXN
	\| RAS-24FSXN
	\| RAS-26FSXN
	\| RAS-28FSXN
	\| RAS-30FSXN
	\| RAS-32FSXN
	\| RAS-34FSXN
	\| RAS-36FSXN
	\| RAS-38FSXN
	\| RAS-40FSXN
	\| RAS-42FSXN
	\| RAS-44FSXN
	\| RAS-46FSXN
	\| RAS-48FSXN
	\| RAS-50FSXN
	\| RAS-52FSXN
	\| RAS-54FSXN
Modular series FSXN1E	\| RAS-8FSXN1E	Not supported	Documentation
	\| RAS-10FSXN1E
	\| RAS-12FSXN1E
	\| RAS-14FSXN1E
	\| RAS-16FSXN1E
	\| RAS-16FSXN1E-P
	\| RAS-18FSXN1E
	\| RAS-20FSXN1E
	\| RAS-22FSXN1E
	\| RAS-24FSXN1E
	\| RAS-26FSXN1E
	\| RAS-28FSXN1E
	\| RAS-30FSXN1E
	\| RAS-32FSXN1E
	\| RAS-32FSXN1E-P
	\| RAS-34FSXN1E
	\| RAS-36FSXN1E
	\| RAS-38FSXN1E
	\| RAS-40FSXN1E
	\| RAS-42FSXN1E
	\| RAS-44FSXN1E
	\| RAS-46FSXN1E
	\| RAS-48FSXN1E
	\| RAS-50FSXN1E
	\| RAS-52FSXN1E
	\| RAS-54FSXN1E
High-efficiency modular series FSXNHE	\| RAS-5FSXNHE	Not supported	Documentation
	\| RAS-6FSXNHE
	\| RAS-8FSXNHE
	\| RAS-10FSXNHE
	\| RAS-12FSXNHE
	\| RAS-12FSXNH-P
	\| RAS-14FSXNHE
	\| RAS-16FSXNHE
	\| RAS-18FSXNHE
	\| RAS-20FSXNHE
	\| RAS-22FSXNHE
	\| RAS-24FSXNHE
	\| RAS-24FSXNH-P
	\| RAS-26FSXNHE
	\| RAS-28FSXNHE
	\| RAS-30FSXNHE
	\| RAS-32FSXNHE
	\| RAS-34FSXNHE
	\| RAS-36FSXNHE
VRF systems
Wall-mounted units (FSN3M)	RPK-0,6FSN3M	Not supported	Documentation
	RPK-0.8FSN3M
	RPK-1.0FSN3M
	RPK-1.5FSN3M
	RPK-2.0FSN3M
	RPK-2.5FSN3M
	RPK-3.0FSN3M
	RPK-4.0FSN3M
Wall-mounted units (FSN2M)	RPK-0.8FSN2M	Not supported	Documentation
	RPK-1.0FSN2M
	RPK-1.5FSN2M
	RPK-2.0FSN2M
	RPK-2.5FSN2M
	RPK-3.0FSN2M
	RPK-4.0FSN2M
Wall-mounted units with an external electronic expansion valve	RPK-0,6FSNH3M	Not supported	Documentation
	RPK-0.8 FSNH3M
	RPK-1.0FSNH3M
	RPK-1.5FSNH3M
Compact four-way cassette units	RCIM 0,6FSN4	Not supported	Documentation
	RCIM-0.8FSN4
	RCIM-1.0FSN4
	RCIM-1.5FSN4
	RCIM-2.0FSN4
	RCIM-2.5FSN4
Four-way cassette units	RCI-1.0FSN3Ei	Not supported	Documentation
	RCI-1.5FSN3Ei
	RCI-2.0FSN3Ei
	RCI-2.5FSN3Ei
	RCI-3.0FSN3Ei
	RCI-4.0FSN3Ei
	RCI-5.0FSN3Ei
	RCI-6.0FSN3Ei
High-efficiency four-way cassette units	RCI-1.0FSN3	Not supported	Documentation
	RCI-1.5FSN3
	RCI-2.0FSN3
	RCI-2.5FSN3
	RCI-3.0FSN3
	RCI-4.0FSN3
	RCI-5.0FSN3
	RCI-6.0FSN3
Two-way cassette units	RCD-1.0FSN2	Not supported	Documentation
	RCD-1.5FSN2
	RCD-2.0FSN2
	RCD-2.5FSN2
	RCD-3.0FSN2
	RCD-4.0FSN2
	RCD-5.0FSN2
High-efficiency ceiling-mounted units	RPC-1.5FSN3	Not supported	Documentation
	RPC-2.0FSN3
	RPC-2.5FSN3
	RPC-3.0FSN3
	RPC-4.0FSN3
	RPC-5.0FSN3
	RPC-6.0FSN3
Ceiling-mounted units	RPC-3.0FSN3E	Not supported	Documentation
	RPC-4.0FSN3E
	RPC-5.0FSN3E
	RPC-6.0FSN3E
Compact ducted units	RPIM-0,6FSN4E	Not supported	Documentation
	RPIM-0,8FSN4E
	RPIM-1,0FSN4E
	RPIM-1,5FSN4E
Low-static ducted units	RPI-0,6FSN4E	Not supported	Documentation
	RPI-0.8FSN4E
	RPI-1.0FSN4E
	RPI-1.5FSN4E
Medium-static ducted units	RPI-2.0FSN4E	Not supported	Documentation
	RPI-2.5FSN4E
	RPI-3.0FSN4E
	RPI-4.0FSN4E
	RPI-5.0FSN4E
	RPI-6.0FSN4E
High-static ducted units	RPI-8.0FSN3E	Not supported	Documentation
	RPI-10.0FSN3E
	RPI-16.0FSN3PE
	RPI-20.0FSN3PE
Floor-standing units with casing	RPF-1.0FSN2E	Not supported	Documentation
	RPF-1.5FSN2E
	RPF-2.0FSN2E
	RPF-2.5FSN2E
Floor-standing units without casing	RPFI-1.0FSN2E	Not supported	Documentation
	RPFI-1.5FSN2E
	RPFI-2.0FSN2E
	RPFI-2.5FSN2E

Air-conditioning series	Model	Gateway	Documentation
Split systems
Series Air Exchanger	RAS-10JH5 \| RAC-10JH5	Not supported	Documentation
	RAS-14JH5 \| RAC-14JH5
Series Premium Inverter	RAS-10MH1 \| RAC-10MH1	HT-1-MB-B	Documentation
	RAS-14MH1 \| RAC-14MH1
	RAS-18MH1 \| RAC-18MH1
	RAS-24MH1 \| RAC-24MH1
	RAS-30MH1 \| RAC-30MH1
Series Inverter	RAS-08PH1 \| RAC-08PH1	HT-1-MB-B	Documentation
	RAS-10PH1 \| RAC-10PH1
	RAS-14PH1 \| RAC-14PH1
	RAS-18PH1 \| RAC-18PH1
Chillers
Samurai RCU2E	40AG2	Not supported	Documentation
	50AG2
	60AG2
	70AG2
	80AG2
	100AG2
	120AG2
	140AG2
	160AG2
	180AG2
	210AG2
	240AG2
	280AG2
	320AG2
	350AG2
	400AG2
SAMURAI RCUE	40WG2	Not supported	Documentation
	50WG2
	60WG2
	80WG2
	100WG2
	120WG2
	150WG2
	180WG2
	200WG2
SAMURAI RCUE	40CLG2	Not supported	Documentation
	50CLG2
	60CLG2
	80CLG2
	100CLG2
	120CLG2

Air-conditioning series	Model	Gateway	Documentation
VRF systems
Wall-mounted units (FSN3M)	RPK-0.8FSN3M	Not supported	Documentation
	RPK-1.0FSN3M
	RPK-1.5FSN3M
	RPK-2.0FSN3M
	RPK-2.5FSN3M
	RPK-3.0FSN3M
	RPK-4.0FSN3M
Wall-mounted units (FSN2M)	RPK-0.8FSN2M	Not supported	Documentation
	RPK-1.0FSN2M
	RPK-1.5FSN2M
	RPK-2.0FSN2M
	RPK-2.5FSN2M
	RPK-3.0FSN2M
	RPK-4.0FSN2M
Wall-mounted units with an external electronic expansion valve	RPK-0.8 FSNH3M	Not supported	Documentation
	RPK-1.0FSNH3M
	RPK-1.5FSNH3M
Compact four-way cassette units	RCIM-0.8FSN2	Not supported	Documentation
	RCIM-1.0FSN2
	RCIM-1.5FSN2
	RCIM-2.0FSN2
Four-way cassette units	RCI-1.0FSN3Ei	Not supported	Documentation
	RCI-1.5FSN3Ei
	RCI-2.0FSN3Ei
	RCI-2.5FSN3Ei
	RCI-3.0FSN3Ei
	RCI-4.0FSN3Ei
	RCI-5.0FSN3Ei
	RCI-6.0FSN3Ei
High-efficiency four-way cassette units	RCI-1.0FSN3E	Not supported	Documentation
	RCI-1.5FSN3
	RCI-2.0FSN3
	RCI-2.5FSN3
	RCI-3.0FSN3
	RCI-4.0FSN3
	RCI-5.0FSN3
	RCI-6.0FSN3
Two-way cassette units	RCD-1.0FSN2	Not supported	Documentation
	RCD-1.5FSN2
	RCD-2.0FSN2
	RCD-2.5FSN2
	RCD-3.0FSN2
	RCD-4.0FSN2
	RCD-5.0FSN2
Ceiling-mounted units	RPC-2.0FSN2E	Not supported	Documentation
	RPC-2.5FSN2E
	RPC-3.0FSN2E
	RPC-4.0FSN2E
	RPC-5.0FSN2E
	RPC-6.0FSN2E
Compact ducted units	RPIM-0.8FSN4E	Not supported	Documentation
	RPIM-1.0FSN4E
	RPIM-1.5FSN4E
	RPIM-0.8FSN4E-DU
	RPIM-1.0FSN4E-DU
	RPIM-1.5FSN4E-DU
Low-static ducted units	RPI-0.8FSN4E	Not supported	Documentation
	RPI-1.0FSN4E
	RPI-1.5FSN4E
Medium-static ducted units	RPI-2.0FSN4E	Not supported	Documentation
	RPI-2.5FSN4E
	RPI-3.0FSN4E
	RPI-4.0FSN4E
	RPI-5.0FSN4E
	RPI-6.0FSN4E
High-static ducted units	RPI-8.0FSN3E	Not supported	Documentation
	RPI-10.0FSN3E
Floor-standing units	RPF-1.0FSN2E	Not supported	Documentation
	RPF-1.5FSN2E
	RPF-2.0FSN2E
	RPF-2.5FSN2E
	RPFI-1.0FSN2E
	RPFI-1.5FSN2E
	RPFI-2.0FSN2E
	RPFI-2.5FSN2E
Kit DX KIT	EXV 2.0E1	Not supported	Documentation
	EXV 2.5E1
	EXV 3.0E1
	EXV 4.0E1
	EXV 5.0E1
	EXV 6.0E1
	EXV 8.0E1
	EXV 10.0E1
Heat-recovery ventilation units KPI series E	KPI 252E3E	Not supported	Documentation
	KPI 502E3E
	KPI 802E3E
	KPI 1002E3E
	KPI 1502E3E
	KPI 2002E3E
Heat-recovery ventilation units KPI series H	KPI 502H3E	Not supported	Documentation
	KPI 802H3E
	KPI 1002H3E
	KPI 1502H3E
	KPI 2002H3E
	KPI 3002H2E
Heat-recovery ventilation units Active KPI. Series X	KPI 502X3E	Not supported	Documentation
	KPI 802X3E
	KPI 1002X3E
VRF outdoor units
Series ES	\| RAS-5HVRNS2E	Not supported	Documentation
	\| RAS-5HRNS2E
	\| RAS-6HVRNS2E
	\| RAS-6HRNS2E
	\| RAS-8HRNSE
	\| RAS-10HRNSE
Series IVX Standart	\| RAS-3HVNC	Not supported	Documentation
	\| RAS-4HVNCE
	\| RAS-4HNCE
	\| RAS-5HVNCE
	\| RAS-5HNCE
	\| RAS-6HVNCE
	\| RAS-6HNCE
	\| RAS-8HNCE
	\| RAS-10HNCE
	\| RAS-12HNC
Series IVX Premium	\| RAS-2HVNP	Not supported	Documentation
	\| RAS-2.5HVNP
	\| RAS-3HVNPE
	\| RAS-4HVNPE
	\| RAS-4HNPE
	\| RAS-5HVNPE
	\| RAS-5HNPE
	\| RAS-6HVNPE
	\| RAS-6HNPE
	\| RAS-8HNPE
	\| RAS-10HNPE
	\| RAS-12HNP
Series IVX Centrifugal with centrifugal fans	\| RASC-5HVRNME	Not supported	Documentation
	\| RASC-10HRNME
Series Set Free Mini	\| RAS-4FSVN2E	Not supported	Documentation
	\| RAS-5FSVN2E
	\| RAS-6FSVN2E
	\| RAS-4FSNY2E
	\| RAS-5FSNY2E
	\| RAS-6FSNY2E
Series Set Free Side Flow	\| RAS-8FSNM	Not supported	Documentation
	\| RAS-10FSNM
	\| RAS-12FSNM
Universal modular series FSXN	\| RAS-8FSXN	Not supported	Documentation
	\| RAS-10FSXN
	\| RAS-12FSXN
	\| RAS-14FSXN
	\| RAS-16FSXN
	\| RAS-18FSXN
	\| RAS-20FSXN		Documentation
	\| RAS-22FSXN
	\| RAS-24FSXN
	\| RAS-26FSXN
	\| RAS-28FSXN
	\| RAS-30FSXN
	\| RAS-32FSXN
	\| RAS-34FSXN
	\| RAS-36FSXN
	\| RAS-38FSXN
	\| RAS-40FSXN
	\| RAS-42FSXN
	\| RAS-44FSXN
	\| RAS-46FSXN
	\| RAS-48FSXN
	\| RAS-50FSXN
	\| RAS-52FSXN
	\| RAS-54FSXN

Air-conditioning series	Model	Gateway	Documentation
Split systems
Series Premium XH	RAS-10XH1 \| RAC-10XH1	HT-1-MB-B	Documentation
	RAS-14XH1 \| RAC-14XH1
Series Eco Sensor	RAS-10SH3 \| RAC-10SH3	HT-1-MB-B	Documentation
	RAS-14SH3 \| RAC-14SH3
	RAS-18SH3 \| RAC-18SH3
Series Air Exchanger	RAS-10JH4 \| RAC-10JH4	Not supported	Documentation
	RAS-14JH4 \| RAC-14JH4
Series Inverter	RAS-08EH4 \| RAC-08EH4	Not supported	Documentation
	RAS-10EH4 \| RAC-10EH4
	RAS-14EH4 \| RAC-14EH4
	RAS-18EH4 \| RAC-18EH4
	RAS-24EH4 \| RAC-24EH4
	RAS-30EH4 \| RAC-30EH2
Series Luxury	RAS-08LH2 \| RAC-08LH1	Not supported	Documentation
	RAS-10LH2 \| RAC-10LH1
	RAS-14LH2 \| RAC-14LH1
	RAS-08LH2B \| RAC-08LH1
	RAS-10LH2B \| RAC-10LH1
	RAS-14LH2B \| RAC-14LH1
	RAS-18LH2 \| RAC-18LH1
	RAS-24LH2 \| RAC-24LH1
Series Business	RAS-08AH1 \| RAC-08AH1	Not supported	Documentation
	RAS-10AH1 \| RAC-10AH1
	RAS-14AH1 \| RAC-14AH1
Series Dualzone	RAS-08QH5E \| RAM-18QH5E	Not supported	Documentation
	RAS-10QH5E \| RAM-18QH5E
	RAS-14QH5E \| RAM-18QH5E
Ducted units series MonoDuct	RAD-50DH7A \| RAC-50DH7	HT-1-MB-B	Documentation
	RAD-60DH7A \| RAC-60DH7
	RAD-70DH7A \| RAC-70DH7
Multi-split systems
Wall-mounted units series Cut Out	RAK-25QH8S(W)(B)	HT-1-MB-B	Documentation
	RAK-35QH8(W)(B)
	RAK-50QH8(W)(B)
Wall-mounted units series Flamed Flat	RAK-18NH6AS	HT-1-MB-B	Documentation
	RAK-25NH6A
	RAK-35NH6A
	RAK-50NH6A
Floor-standing units	RAF-25NX2	HT-1-MB-B	Documentation
	RAF-35NX2
	RAF-50NX2
Cassette units	RAI-25NH5A	HT-1-MB-B	Documentation
	RAI-35NH5A
	RAI-50NH5A
Ducted units	RAD-18NH7A	HT-1-MB-B	Documentation
	RAD-25NH7A
	RAD-35NH7A
	RAD-50NH7A
Outdoor units
Outdoor units series Multizone	\| RAM-35QH5	Not supported	Documentation
	\| RAM-52QH5
	\| RAM-53QH5
	\| RAM-71QH5
	\| RAM-90QH5
	\| RAM-130QH5

Connector	Gateway
Connector	Modbus	Zigbee
CN7, CN1101 Connector on the indoor-unit PCB	HT-1-MB-B	HT-1-ZB-S

Gateways for Hitachi air conditioners
Smart-home and building automation

1. Connection options

1.1 Connector example CN7

1.2 Connector example CN1101

2. Compatible air-conditioning models

2.1 Air conditioners: 2025

2.2 Air conditioners: 2024

2.3 Air conditioners: 2022

2.4 Air conditioners: 2021

2.5 Air conditioners: 2020

2.6 Air conditioners: 2019

2.7 Air conditioners: 2018

2.8 Air conditioners: 2015

2.9 Air conditioners: 2014

2.10 Air conditioners: 2013

2.11 Air conditioners: 2012

Gateways for Hitachi air conditionersSmart-home and building automation

1. Connection options

1.1 Connector example CN7

1.2 Connector example CN1101

2. Compatible air-conditioning models

2.1 Air conditioners: 2025

2.2 Air conditioners: 2024

2.3 Air conditioners: 2022

2.4 Air conditioners: 2021

2.5 Air conditioners: 2020

2.6 Air conditioners: 2019

2.7 Air conditioners: 2018

2.8 Air conditioners: 2015

2.9 Air conditioners: 2014

2.10 Air conditioners: 2013

2.11 Air conditioners: 2012

Gateways for Hitachi air conditioners
Smart-home and building automation
